Concepts

Concepts

<!-- overview -->

The Concepts section helps you learn about the parts of the Kubernetes system and the abstractions Kubernetes uses to represent your {{< glossary_tooltip text="cluster" term_id="cluster" length="all" >}}, and helps you obtain a deeper understanding of how Kubernetes works.

<!-- body -->

---

Cluster Architecture

A Kubernetes cluster consists of a control plane plus a set of worker machines, called nodes, that run containerized applications. Every cluster needs at least one worker node in order to run Pods.

The worker node(s) host the Pods that are the components of the application workload. The control plane manages the worker nodes and the Pods in the cluster. In production environments, the control plane usually runs across multiple computers and a cluster usually runs multiple nodes, providing fault-tolerance and high availability.

This document outlines the various components you need to have for a complete and working Kubernetes cluster.

{{< figure src="/images/docs/kubernetes-cluster-architecture.svg" alt="The control plane (kube-apiserver, etcd, kube-controller-manager, kube-scheduler) and several nodes. Each node is running a kubelet and kube-proxy." caption="Figure 1. Kubernetes cluster components." class="diagram-large" >}}

{{< details summary="About this architecture" >}} The diagram in Figure 1 presents an example reference architecture for a Kubernetes cluster. The actual distribution of components can vary based on specific cluster setups and requirements.

In the diagram, each node runs the kube-proxy component. You need a network proxy component on each node to ensure that the {{< glossary_tooltip text="Service" term_id="service">}} API and associated behaviors are available on your cluster network. However, some network plugins provide their own, third party implementation of proxying. When you use that kind of network plugin, the node does not need to run kube-proxy. {{< /details >}}

Control plane components

The control plane's components make global decisions about the cluster (for example, scheduling), as well as detecting and responding to cluster events (for example, starting up a new {{< glossary_tooltip text="pod" term_id="pod">}} when a Deployment's {{< glossary_tooltip text="replicas" term_id="replica" >}} field is unsatisfied).

Control plane components can be run on any machine in the cluster. However, for simplicity, setup scripts typically start all control plane components on the same machine, and do not run user containers on this machine. See Creating Highly Available clusters with kubeadm for an example control plane setup that runs across multiple machines.

kube-apiserver

{{< glossary_definition term_id="kube-apiserver" length="all" >}}

etcd

{{< glossary_definition term_id="etcd" length="all" >}}

kube-scheduler

{{< glossary_definition term_id="kube-scheduler" length="all" >}}

kube-controller-manager

{{< glossary_definition term_id="kube-controller-manager" length="all" >}}

There are many different types of controllers. Some examples of them are:

• Node controller: Responsible for noticing and responding when nodes go down.
• Job controller: Watches for Job objects that represent one-off tasks, then creates Pods to run those tasks to completion.
• EndpointSlice controller: Populates EndpointSlice objects (to provide a link between Services and Pods).
• ServiceAccount controller: Create default ServiceAccounts for new namespaces.

The above is not an exhaustive list.
